Tubing, Fittings
and Connectors |
1/2" ID
Tubing |
| |
Thick walled (3/32) to prevent kinking.
|
|
5/16" ID
Tubing |
| |
Thick walled (3/32) to prevent kinking.
|
|
1/4" OD PVC
Tubing |
| |
1/4" OD (1/8" ID) PVC tubing.
|
|
1/4" OD
Tubing |
| |
1/4" OD LLDPE tubing, commonly used with reverse osmosis systems and solenoid valves.
|
|
| 1/4" Tubing Mounting Clip |
| |
Each clip secures 1 or 2 tubes. Includes a mounting screw.
|
|
| Tubing Adapter |
| |
Adapter converts 1/2" or 5/16" pump output to 1/4 OD tubing. This will allow you to use smaller tubing for your topoff pump.
|
|
| Snail Guard |
|
Use this to minimize excessive switching from waves in your sump or tank. This will also prevent inhabitants from
interfering with the operation of your topoff controller.
|
|
| Float Switch |
|
Madison M8000 float switch with 22" wire leads.
|
|
| Upper Float Switch |
|
Madison M8000 float switch with 22" wire leads. Includes angle bracket for attaching to one of our mounting brackets.
|
|
| Lower Float Switch |
|
Madison M8000 float switch with 22" wire leads. Includes PVC surround to protect the switch and prevent excess switching. Will also accomodate a snail guard.
|
|
| Nano Float Switch & Bracket |
|
Madison M8000 float switch with 22" wire leads. Includes small footprint mounting bracket to accomodate tight spaces. Water level is adjustable from 1.5-7" below top of tank. This is for the float switch & mounting bracket only, if you need a nano controller they are available on our custom page.
|
|
| Sump Mounting Bracket |
|
Use our float switch mounting brackets to hang any type of
device to your tank, sump, etc. Includes necessary zipties.
This mounting bracket is 2" wide and 12" long and has two 2 rows of holes that allow
you to mount one or two float switches above one another. This will allow you to set your water level
anywhere between 1" and 9" below the top of your tank.
|
|
| Tank Mounting Bracket |
|
Use our float switch mounting brackets to hang any type of
device to your tank, sump, etc. Includes necessary zipties.
This mounting bracket is 2" wide and 7" long and has two 2 rows of holes that allow
you to mount one float switches to approx. 3" below the top of your tank.
|
|
| Plastic Stock |
|
This is just a flat piece of plastic, no holes, no bends. It is the same plastic that we use to create our mounting brackets.
|
|
| Mount Extensions |
|
This is a flat piece of plastic with holes drilled in it. You can attach to your mounting bracket using the included zip tie which will allow you to mount the float switch lower in your tank.
|
|
| Float Valve |
| |
7.5" long with adjustable arm. Plastic with stainless steel hardware. Can be used both vertically and horizontally.
Valves have a .093 orifice and have been tested to 100 psi. Requires 7/16" hole for mounting.
|
|
| 1/4" Ball
Valve |
|
| 1/4" FPT Tank Ball
Valve |
|
Used to connect to an RO pressurized storage tank.
|
|
| 1/4" Union
T |
|
| 1/4" MPT x 1/4"
Tube |
|
Fitting used on the inline carbon filter or the slim line filter housing.
|
|
| 1/8" MPT x 1/4"
Tube |
|
Fitting used on our solenoid valves.
|
|
| 1/8 FPT x 1/4 Tube |
|
| 1/4" Bulkhead |
|
1/4" Bulkhead Union. 1/4" quick connect on each side each. Max thickness .60", requires .70" hole diameter
|
|
| 1/8" MPT x 3/8"
Tube |
|
Fitting for our solneoid valves except for 3/8" tubing.
|
|
| 1/8" MPT x 1/4"
Stem |
|
Fitting for our solenoid valves used to connect two together in series.
|
|
| 1/8" MPT x 3/8" Barb |
|
Fitting for our solenoid valve used to connect 3/8" tubing.
|
|
| Fitting Release Tool |
| |
Release tool for 1/4", 3/8" & 1/2" fittings.
|
|
| Garden Hose Adapter |
| |
3/4" female garden hose thread to 1/4" quick connect with dual o-rings.
|
|
| Faucet
Adapter |
| |
1/2" Male to 1/2" Female with 1/4" quick connect. Use to connect
into your houshold water system.
|
|
| Angle Stop Adapter |
| |
3/8" Male to 3/8" Female with 1/4" quick connect. Use to connect
into your houshold water system. Insert white gasket into female threads. Finger tighten 1 additional turn when resistance is felt.
|
|
| Sediment Filter |
| |
1 Micron. Spun Polypropylene. 2.5"x 9.88"
|
|
| Carbon Block Filter |
| |
Matrikx CT0 Carbon Block Filter. 6000gal Chlorine plus taste & Odor Reduction, 5 Micron, 1gpm, 2.5"x 9.88",
|
|
| Inline Carbon Filter |
| |
Service life 1 year or 1,500 gallon. Requires 1/4" MPT fittings (sold separately above).
|
|
| Slim Filter Housing |
| |
Pentek Slim Line Blue Filter Housing. 10" length, Requires 1/4" MPT fittings (sold separately above).
|
|
| Single Filter Housing Bracket |
| |
Bracket which holds one slim blue filter housing.
|
|
| Filter Housing Screw |
| |
Use to attach filter housing to bracket.
|
|
| Slim Filter Wrench |
| |
Slim filter housing spanner wrench. Makes changing filters a snap.
|
|
| 75 GPD
Membrane |
| |
GE Osmonics Thin Film Composite Reverse Osmosis Membrane.
75 Gallon/Day. 1.75" x 11.75"
|
|
| RO Membrane Housing |
| |
Reverse Osmosis Membrane Housing. Requires three 1/8" fittings (inlet, outlet, waste).
|
|
| Flow Restrictor |
| |
575 ML/min Flow restrictor for 75GPD RO membranes. You need to replace your flow restrictor
when chaning membrane sizes.
|
|
| TDS Meter |
| |
Digital handheld TDS meter. Use this to test your filter's output so you know when your RO system needs service.
|
|
| Inline Dual TDS Meter |
| |
HM Digital DM-1. Use this to test your filter's output so you know when your RO system needs service.
|
|
| Auto Shutoff Valve |
|
| Check Valve |
| |
Acetal Check Valve Insert, Dual EPDM O-rings, .3 psi cracking pressure
|
|
| Leak Controller |
| |
Upon sensing moisture, this will engage the shut-off valve and sound an alarm. Includes four AA batteries.
|
|
